Description

Superior Performance

Facing rapid technological advancements, GIGABYTE consistently stays ahead of the curve, providing customers with cutting-edge features and technologies. GIGABYTE motherboards feature upgraded power solutions, the latest storage standards, and excellent connectivity options to ensure optimal gaming performance.

Connectivity

GIGABYTE motherboards offer unparalleled connectivity and extremely fast data transfer speeds.

Personalization

GIGABYTE motherboards come pre-installed with a variety of practical and intuitive applications to help users take control of every aspect of their motherboard.

Features

Socket

Socket AM5

Chipset (Northbridge)

AMD B650

Form Factor

ATX

Memory Support

4 x DDR5 DIMM slots; 2 channels

M.2 (NGFF) Connector Count

3 pieces

Wireless Interface

802.11 a/b/g/n/ac/ax

Bluetooth

Processor Support

AMD Ryzen 7000/8000/9000 series

Max Memory Frequency

8000 MHz

Network Interface

1 x 1 Gigabit/s

Embedded Video

Supports processor video cores

Country of Origin

China

PCI Express x16

1 x PCI-E 4.0 x16 slot

3 x PCI-E 3.0 x16 (x1) slots

Video Output

1 x HDMI Interfaces

DisplayPort

Maximum Memory

256GB (8000 (overclocked)/7800 (overclocked)/7600 (overclocked)/7200 (overclocked)/7000 (overclocked)/6800 (overclocked)/6600 (overclocked)/6400 (overclocked)/6200 (overclocked)/6000 (overclocked)/5600 (overclocked)/5200/4800/4400MHz)

USB

1 USB Type-C port

2 USB 3.2 ports

6 USB 2.0 ports

Power Connector

1 24-pin ATX power connector

1 8-pin ATX power connector, 12V

Digital Audio Interface (S/PDIF)

No digital audio output

Built-in Audio

Realtek 7.1-channel HDA codec

SATA II Connector Quantity

None

SATA III Connector Quantity

4 Components

RAID Controller

0

1

10

External Connectors

1 PS/2 Keyboard/Mouse Combo Port

1 HDMI Port

1 DisplayPort Port

6 USB 2.0 Ports

1 USB 3.2 Type-C Gen1 Port

2 USB 3.2 Gen2 Ports

2 SMA Antenna Interfaces (2T2R)

1 LAN (RJ-45) Port

3 Audio Interfaces

Video output only works if the processor has an integrated graphics core.

Number of Processor Sockets

1

Number of Memory Slots

4

Physical Dimensions

30.5 x 24.4 cm

Number of LAN Ports

1

Cooling

Passive

Audio Jacks

3 Mini Jacks

Built-in Backlight

No Backlight

Board Color

Black with Gray

Country of Brand Registration

China (Taiwan)

Warranty

36 Months

EAN

4719331860158
